产品概述
本系列产品是为管道增压输送，解决管道压力过低而研制的电泵。
产品用途
供输送清水及物理化学性质类似于清水的其它液体之用，适用于工业和城市给排水、高层建筑增压送水、园林喷灌、消防增压、远距离输送、暖通制冷循环、浴室等冷暖循环增压及设备配套。
使用条件
1.泵系统工作压力≤1.6MPa，即泵吸入口压力+泵扬程≤1.6MPa（订货时注明泵系统工作压力，泵系统工作压力大于1.6MPa时应在订货时另行提出。以便在制造泵的过流部分和联接部分采用铸钢材料）。
2.环境温度＜40℃，相对温度＜95℃，海拔高度不超过1000米。
3.水质为清水，不应有纤维或固体颗粒，对热水应为软水。
4.泵运行时，电源电压波动范围为额定值的±10%。
| 型号 | 流量(m³/h) | 扬程(m) | 功率(kW) | 转速(r/min) |
| 25-125 | 4 | 20 | 0.75 | 2900 |
| 25-160 | 4 | 32 | 1.5 | 2900 |
| 25-160A | 3.7 | 28 | 1.1 | 2900 |
| 32-125 | 5 | 20 | 0.75 | 2900 |
| 32-160 | 5 | 32 | 1.5 | 2900 |
| 32-160A | 5 | 28 | 1.1 | 2900 |
| 32-200 | 5 | 50 | 3 | 2900 |
| 32-200A | 4.5 | 40 | 2.2 | 2900 |
| 40-100 | 6.3 | 12.5 | 0.75 | 2900 |
| 40-125 | 6.3 | 20 | 1.1 | 2900 |
| 40-125A | 5.6 | 16 | 0.75 | 2900 |
| 40-160 | 6.3 | 32 | 2.2 | 2900 |
| 40-160A | 5.5 | 28 | 1.5 | 2900 |
| 40-160B | 5 | 24 | 1.1 | 2900 |
| 40-200 | 6.3 | 50 | 4 | 2900 |
| 40-200A | 5.5 | 44 | 3 | 2900 |
| 40-200B | 5 | 38 | 2.2 | 2900 |
| 40-250 | 6.3 | 80 | 7.5 | 2900 |
| 40-250A | 5.5 | 70 | 5.5 | 2900 |
| 40-250B | 5 | 60 | 4 | 2900 |
| 40-100(I) | 12.5 | 12.5 | 1.1 | 2900 |
| 40-100(I)A | 11 | 10 | 0.75 | 2900 |
| 40-125(I) | 12.5 | 20 | 1.5 | 2900 |
| 40-125(I)A | 11 | 16 | 1.1 | 2900 |
| 40-160(I) | 12.5 | 32 | 3 | 2900 |
| 40-160(I)A | 11 | 28 | 2.2 | 2900 |
| 40-160(I)B | 10 | 24 | 1.5 | 2900 |
| 40-200(I) | 12.5 | 50 | 5.5 | 2900 |
| 40-200(I)A | 11 | 44 | 4 | 2900 |
| 40-200(I)B | 10 | 38 | 3 | 2900 |
| 40-250(I) | 12.5 | 80 | 11 | 2900 |
| 40-250(I)A | 11 | 70 | 7.5 | 2900 |
| 40-250(I)B | 10 | 60 | 5.5 | 2900 |
| 50-100 | 12.5 | 12.5 | 1.1 | 2900 |
| 50-100A | 11 | 10 | 0.75 | 2900 |
| 50-125 | 12.5 | 20 | 1.5 | 2900 |
| 50-125A | 11 | 16 | 1.1 | 2900 |
| 50-160 | 12.5 | 32 | 3 | 2900 |
| 50-160A | 11 | 28 | 2.2 | 2900 |
| 50-160B | 10 | 24 | 1.5 | 2900 |
| 50-200 | 12.5 | 50 | 5.5 | 2900 |
| 50-200A | 11 | 44 | 4 | 2900 |
| 50-200B | 10 | 38 | 3 | 2900 |
| 50-250 | 12.5 | 80 | 11 | 2900 |
| 50-250A | 11 | 70 | 7.5 | 2900 |
| 50-250B | 10 | 60 | 5.5 | 2900 |
| 50-100(I) | 25 | 12.5 | 1.5 | 2900 |
| 50-100(I)A | 22 | 10 | 1.1 | 2900 |
| 50-125(I) | 25 | 20 | 3 | 2900 |
| 50-125(I)A | 22 | 16 | 2.2 | 2900 |
| 50-125(I)B | 20 | 13 | 1.5 | 2900 |
| 50-160(I) | 25 | 32 | 4 | 2900 |
| 50-160(I)A | 22 | 28 | 3 | 2900 |
| 50-160(I)B | 20 | 24 | 2.2 | 2900 |
| 50-200(I) | 25 | 50 | 7.5 | 2900 |
| 50-200(I)A | 22 | 44 | 5.5 | 2900 |
| 50-200(I)B | 20 | 38 | 4 | 2900 |
| 50-250(I) | 25 | 80 | 15 | 2900 |
| 50-250(I)A | 22 | 70 | 11 | 2900 |
| 50-250(I)B | 20 | 60 | 7.5 | 2900 |
| 50-315(I) | 25 | 125 | 30 | 2900 |
| 50-315(I)A | 23.7 | 113 | 22 | 2900 |
| 65-100 | 25 | 12.5 | 1.5 | 2900 |
| 65-100A | 23 | 10 | 1.1 | 2900 |
| 65-125 | 25 | 20 | 3 | 2900 |
| 65-125A | 23 | 16 | 2.2 | 2900 |
| 65-125B | 20 | 13 | 1.5 | 2900 |
| 65-160 | 25 | 32 | 4 | 2900 |
| 65-160A | 22 | 28 | 3 | 2900 |
| 65-160B | 20 | 24 | 2.2 | 2900 |
| 65-200 | 25 | 50 | 7.5 | 2900 |
| 65-200A | 22 | 44 | 5.5 | 2900 |
| 65-200B | 20 | 38 | 4 | 2900 |
| 65-250 | 25 | 80 | 15 | 2900 |
| 65-250A | 22 | 70 | 11 | 2900 |
| 65-250B | 20 | 60 | 7.5 | 2900 |
| 65-315 | 25 | 125 | 30 | 2900 |
| 65-315A | 23 | 113 | 22 | 2900 |
| 65-315B | 22 | 101 | 18.5 | 2900 |
| 65-100(I) | 50 | 12.5 | 3 | 2900 |
| 65-100(I)A | 44 | 10 | 2.2 | 2900 |
| 65-125(I) | 50 | 20 | 5.5 | 2900 |
| 65-125(I)A | 44 | 16 | 4 | 2900 |
| 65-160(I) | 50 | 32 | 7.5 | 2900 |
| 65-160(I)A | 44 | 28 | 5.5 | 2900 |
| 65-160(I)B | 40 | 24 | 4 | 2900 |
| 65-200(I) | 50 | 50 | 15 | 2900 |
| 65-200(I)A | 44 | 40 | 11 | 2900 |
| 65-200(I)B | 40 | 38 | 7.5 | 2900 |
| 65-250(I) | 50 | 80 | 22 | 2900 |
| 65-250(I)A | 44 | 70 | 18.5 | 2900 |
| 65-250(I)B | 40 | 60 | 15 | 2900 |
| 80-100 | 50 | 12.5 | 3 | 2900 |
| 80-100A | 44 | 10 | 2.2 | 2900 |
| 80-125 | 50 | 20 | 5.5 | 2900 |
| 80-125A | 44 | 16 | 4 | 2900 |
| 80-160 | 50 | 32 | 7.5 | 2900 |
| 80-160A | 44 | 28 | 5.5 | 2900 |
| 80-160B | 40 | 24 | 4 | 2900 |
| 80-200 | 50 | 50 | 15 | 2900 |
| 80-200A | 44 | 44 | 11 | 2900 |
| 80-200B | 40 | 38 | 7.5 | 2900 |
| 80-250 | 50 | 80 | 22 | 2900 |
| 80-250A | 44 | 70 | 18.5 | 2900 |
| 80-250B | 40 | 60 | 15 | 2900 |
| 80-315 | 50 | 125 | 37 | 2900 |
| 80-315A | 44 | 113 | 30 | 2900 |
| 80-100(I) | 100 | 12.5 | 5.5 | 2900 |
| 80-100(I)A | 88 | 10 | 4 | 2900 |
| 80-125(I) | 100 | 20 | 11 | 2900 |
| 80-125(I)A | 88 | 16 | 7.5 | 2900 |
| 80-160(I) | 100 | 32 | 15 | 2900 |
| 80-160(I)A | 88 | 28 | 11 | 2900 |
| 80-160(I)B | 80 | 24 | 7.5 | 2900 |
| 80-200(I) | 100 | 50 | 22 | 2900 |
| 80-200(I)A | 88 | 44 | 18.5 | 2900 |
| 80-200(I)B | 80 | 38 | 15 | 2900 |
| 80-250(I) | 100 | 80 | 37 | 2900 |
| 80-250(I)A | 88 | 70 | 30 | 2900 |
| 80-250(I)B | 80 | 60 | 22 | 2900 |
| 100-100 | 100 | 12.5 | 5.5 | 2900 |
| 100-100A | 88 | 10 | 4 | 2900 |
| 100-125 | 100 | 20 | 11 | 2900 |
| 100-125A | 88 | 16 | 7.5 | 2900 |
| 100-160 | 100 | 32 | 15 | 2900 |
| 100-160A | 88 | 28 | 11 | 2900 |
| 100-160B | 80 | 24 | 7.5 | 2900 |
| 100-200 | 100 | 50 | 22 | 2900 |
| 100-200A | 88 | 44 | 18.5 | 2900 |
| 100-200B | 80 | 38 | 15 | 2900 |
| 100-250 | 100 | 80 | 37 | 2900 |
| 100-250A | 88 | 70 | 30 | 2900 |
| 100-250B | 80 | 60 | 22 | 2900 |
| 100-160(I)A | 150 | 28 | 18.5 | 2900 |
| 100-200(I) | 160 | 50 | 37 | 2900 |
| 100-200(I)A | 150 | 44 | 30 | 2900 |
| 125-125 | 160 | 20 | 11 | 2900 |
| 125-125A | 143 | 16 | 7.5 | 2900 |
| 125-160 | 160 | 32 | 22 | 2900 |
| 125-160A | 150 | 28 | 18.5 | 2900 |
| 125-160B | 138 | 24 | 15 | 2900 |
| 125-200 | 160 | 50 | 37 | 2900 |
| 125-200A | 150 | 44 | 30 | 2900 |
| 125-200B | 138 | 38 | 22 | 2900 |
| 125-250B | 138 | 60 | 37 | 2900 |
| 150-125 | 160 | 20 | 11 | 2900 |
| 150-125A | 143 | 16 | 7.5 | 2900 |
| 150-160 | 160 | 32 | 22 | 2900 |
| 150-160A | 150 | 28 | 18.5 | 2900 |
| 150-160B | 138 | 24 | 15 | 2900 |
| 150-200 | 160 | 50 | 37 | 2900 |
| 150-200A | 150 | 44 | 30 | 2900 |
| 150-200B | 138 | 38 | 22 | 2900 |
| 150-250B | 138 | 60 | 37 | 2900 |
